ROADVISION
Roadvision LED Beacon Micro Revolver Series 10-30V Amber Fixed Mount 32SMD LEDs 28W 10 Function SAE Class 1
Roadvision LED Beacon Micro Revolver Series 10-30V Amber Fixed Mount 32SMD LEDs 28W 10 Function SAE Class 1
SKU:RB112Y
Couldn't load pickup availability
Share
PRODUCT DETAILS
Roadvision LED Beacon Micro Revolver Series 10-30V Amber Fixed Mount 32SMD LEDs 28W 10 Function SAE Class 1
Roadvision's RB112Y Series compact 360 high intensity beacons are at the forefront of automotive lighting technology..... Featuring state-of-the art LED technology, the REVOLVER Series of Roadvision LED beacons are specifically designed and engineered to not only meet, but exceed Australian and international regulations. With a tough Aluminium housing and impact resistant polycarbonate lens, the RB112 Series are built to last in even the toughest conditions. Featuring 32 SMD LED's and with 10 selectable flash patterns - including single, double, triple, quad & simulated rotating.
In addition you have the option of alternate synchronization & synchronization - the RB112 Series are the perfect LED beacon for a wide range of industrial applications. Compact low profile 10 function 360 high intensity beacons Single, double, triple, quad & simulated rotating flash patterns Multi-volt 10-30V input & low current draw 32 SMD LED's produce 28W 100,000 hour rated LED lifespan Maintenance free solid state technology Tough polycarbonate lens & alluminium body Waterproof IP67 rated and vibration proof Compact low profile 112 x 48mm body Available in 3 hole fixed, magnetic or DIN Pole mounts EMC, CISPR25 Class 5 & SAE J845 Class 1 approved.
Specifications:
| Wiring Code 1 | Red - Positive Supply |
|---|---|
| Wiring Code 2 | White - Negative |
| Wiring Code 4 | Yellow Alternate Sync Enable |
| Wiring Code 3 | Brown - Flash Pattern Select (Sync) |
| Flash Patterns | 10 Flash Patterns |
| Wiring | red: +ve, blue: -ve, grn: pattern |
| Brand | ROADVISION |
| Voltage | 10-30V |
| Approvals | EMC CISPR25 Class 5 & SAE Class 1 |
| Dimensions | 112 x 48mm |
