Product Description
PRE-ORDER: bus bars ETA is approximately early November.
PRODUCT DETAILS
Complete 250A power distribution kit
Positive and negative 4 way distribution blocks plus a matching 250A manual reset circuit breaker. Each stud is capable of 62.5amp of continuous current.
In the pack:
- 1 x 4 Way Distribution Block Positive 8mm studs, 250A – VES117
- 1 x 4 Way Distribution Block Negative 8mm studs, 250A – VES118
- 1 x 250AMP VES Surface Mount Manual Resettable Circuit Breaker – VES146-250
Distribution blocks:
- Nickel plated brass contact plates for optimal current transfer and weather resistance
- Nylon base for excellent insulation and strength
- Stainless steel hardware – rust resistant, suitable for marine environments
- Removable protective cover on each block
- Maximum voltage 48V DC
Circuit breaker:
- Heavy duty surface mount circuit breaker with manual reset
- Rated up to 48V DC – suits 12/24/36/48V systems
- Ignition protected
Individual SKUs included:
- 1x VES117 | 4 Way Distribution Block Positive 8MM Studs 250AMP Rated
- 1x VES118 | 4 Way Distribution Block Negative 8MM Studs 250AMP Rated
- 1x VES146-250 | 250AMP VES Surface Mount Manual Resettable Circuit Breaker
