FEATURES:
- 100% Drawer extension for complete access
- Patented “Stay-Open Block”
- Rust resistant sealed bearings with Nylon rollers
- Internal LED Light Strip
- Safe and secure lock system
- Dust resistant seal
- Stainless steel fasteners
INCLUDES:
- Cargo Barrier mounting points
- Child restraint points
- MSA 4X4’s Lifetime Guarantee
DIMENSIONS:
EXTERNAL DIMENSIONS +10mm for rear anchor bolts
- Overall drawer length = 1045mm (including handle lock)
- Overall drawer height = 275mm
- Overall single drawer width = 510mm (no wings)
INTERNAL DIMENSIONS
- Usable drawer height = 215mm (up to the underside of the top deck)
- Drawer height = 211mm
- Internal drawer length = 930mm
- Internal drawer width = 433mm
WEIGHT
Note: MSA 4X4 Storage Drawer Systems are designed to fit directly into the vehicle tub body. It is not designed to fit in conjunction with a tub liner. Tub liners MUST be removed before installation.
