Hard Korr

Hard Korr Single Row Light Bar Hyperion 10″

Hard Korr Single Row Light Bar Hyperion 10″

SKU:HKLB-HPR-10S

Regular price $189.00 AUD
Regular price Sale price $189.00 AUD
Sale Sold out
Tax included.

Hard Korr Single Row Light Bar Hyperion 10″

A lightbar that’s distinctly yours.

  • 1 LUX @ 300M
  • PREMIUM OSRAM LEDs
  • IP68/IP69K WATERPROOF & DUSTPROOF
  • HYPERFLOOD 180° BEAM
  • COLOR TEMPERATURE 5700K
  • CISPR25 CERTIFIED EMC PROTECTION

Our Hyperion LED light bars combine outstanding real-world performance and toughness with an aggressive design and extensive customisation options.

Top quality LED chips and reflectors

Starting with the basics, this light bar is constructed with high-performance OSRAM® OSLON SSL 150 LED chips. These premium chips are extremely efficient, supremely robust, resistant to corrosion and have a 150° viewing angle, which is very important in light bar applications where beam width is key. They also have very low thermal resistance, which means they will remain cooler than other LED chips and their performance will not degrade with extended use. The 5700K colour temperature offers balanced, natural lighting for excellent visibility without causing eye strain from glare.

We have matched these chips with expertly engineered, vacuum-metallised polycarbonate reflectors, which allowed us to create a 180 degree overall beam angle. This means not only can you see far into the distance, but are also made aware of close-up hazards such as kangaroos in time to take evasive action.

Robotic manufacturing

The housing and lens are robotically manufactured and assembled, ensuring the light bar is perfectly sealed against dust and water ingress, and we use the highest quality materials to ensure they’ll last for many years even in harsh conditions.

Intelligent design

Because single row light bars are often used in tight spaces such as inside grilles and underneath roof racks, we have engineered our Hyperion light bars to be as thin as possible by minimising wasted space internally. When using the end-mount legs this bar is only 52.1mm high, and when using the under-mount legs it is still only 63.6mm high.

Extensively customisable

Finally, we’ve made sure there is plenty of customisability so you have the freedom to match this light bar to your vehicle and application. We’ve included three pairs of different coloured side inserts in the pack, and have another seven colour options available for separate purchase. Additionally, each light bar can be switched between high and low modes, and you can also switch between orange and white daytime running lights (DRLs). For further protection and customisation, we also offer black, orange and clear covers for purchase.

Tested Tough

We’ve engineered these lights to be incredibly durable and reliable, and extensively tested them to ensure they will still perform even under extreme duress in real-world Australian conditions. They are certified as compliant with the following standards:

  • IP68 & IP69K: Completely resistant to dust ingress (IP6X), can handle submersion in 3m of water for 30 minutes (IPX8) as well as high-pressure, high-temperature water jets (IPX9K)
  • UNECE R10 (CISPR25): Will not unduly interfere with radio signals

In addition, our manufacturing facility has been certified in accordance with the following international standards:

  • ISO 9001: Ensures quality management systems have been implemented
  • ISO 14001: Ensures environmental management systems have been implemented

Powerful, even combination beam. 180º coverage.

Two brightness settings, and a powerful combination beam pattern will give you the spread and reach that you need for any situation.

Drag the slider to see how your forward view changes when you use a Hardkorr Hyperion LED light bar compared to normal high beam headlights.

*Hyperion 50″ model shown

The Hardkorr guarantee

All Hardkorr products are manufactured using the highest quality materials. We are confident that they are the most durable in the market and will give you many years of reliable service. We stand behind this product with a comprehensive 5 year Australian warranty and a 30-day money back guarantee. For terms and conditions click here.

Specifications

Materials 6063 aluminium housing
UV hardcoated polycarbonate lens
Vacuum-metallised aluminium reflectors
LED type OSRAM OSLON® SSL 150
Power 45W
Beam distance 1 lux @ 300m (high) / 1 lux @ 127m (low)
Output (raw) 3,780 lumens
Output (effective) 2,700 lumens (high) / 488 lumens (low)
Peak intensity 90,000 candela
Colour temperature 5700K
DRL colour Settable orange / white
Operating voltage 10 – 30V DC
Current draw (12V) 3.09A (high) / 0.58A (low)
Current draw (24V) 1.6A (high) / 0.29A (low)
DRL power draw 0.25A @ 12V / 0.14A @ 24V
Operating temperature -30°C to 65°C
Weight 0.8kg
Certifications CE, CISPR25, ISO 7637-2:2004

Pack Contents

1x 10" Hyperion LED light bar
1x Set end-mount legs
1x Set under-mount legs
1x Wiring harness
3x pair Coloured inserts (blue, black, grey)

Dimensions

Hardkorr Hyperion 10 inch dimension diagram
