iTECHBC40 Intelligent Battery Charger 12V 40A

iTECHBC40 Intelligent Battery Charger 12V 40A

SKU:iTECHBC40

Regular price $349.00 AUD
Regular price $399.00 AUD Sale price $349.00 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

PRODUCT DETAILS

iTECHBC40 Intelligent Battery Charger 12V 40A

The iTECHBC40 40A AC Intelligent Battery Charger is a fully automatic "set and forget" charger. It has been designed and developed to charge Lithium LiFEPO4 batteries fast, efficient and effective, with unique algorithms that help maximise your battery's service life. The iTECHBC40 is a smart multistage battery charger that utilises the latest switch-mode battery charging technology, allowing your charger to be permanently connected to your battery bank.

The multistage charging algorithm delivers a fast, efficient and consistent charge with no voltage drop. Using charge algorithms that are tailor-made for Lithium LiFePO4 batteries, the iTECHBC40 not only charges the battery but looks after it. The iTECHBC40 is unlike any other battery charger on the market; with lithium LiFePO4 batteries as the focus, it will maximise and extend your battery's service life.

The iTECHBC40 has an innovative boost charge feature; this helps activate an iTechworld lithium battery from safe mode.

Designed and developed in Australia, the iTECHBC40 is built for the harsh Australian climate. The iTECHBC40 has a thermally cooling fan that automatically switches on and off based on the internal charger temperature to handle extreme conditions.

The iTECHBC40 battery charger uses a micro control system to manage the battery charging process.

Package Contents

  • 1x iTechworld iTECHBC40 40A Battery Charger
  • 1x Power lead
  • 1x Set of 12v 800mm heavy duty battery leads with M8 eyelets/ring terminals
  • 1x Instruction manual HERE
General
Battery capacity: 100-1200Ah
Maximum input current: 4.8A
Input fuse rating: 80A
Continuous output current: Up to 40A
Output fuse rating: 60A
Minimum auxiliary battery charge start voltage 4V
Standby current: <18mA
Battery type: Standard lead-acid, Gel, AGM, Calcium & LiFePO4
Operating temperature: -20°C ~ 80°C
IP rating: IP20
Dimensions 275 x 187 x 70mm
Weight: 2.5kg
Output
Charge type: 4-Stage
Charging profile: STD Gel AGM Calcium LiFePO4
Bulk: 40A
Absorption: 14.4V 14.1V 14.7V 15.5V 14.4V
Float voltage: 13.4V 13.5V 13.4V 13.6V
